Peddicat No. 1

350x13	100x8	30 32	10	100x10	Ø31 in 12

Peddiworker No. 1

400x20	120x10	40  40	13	Ø31 in 22

Peddimax No. 1

Hydraulic 280

Standard	Option
Ø31 in 7 Ø22 in 10 Ø15 in 15	Ø58 in 4 Ø65 in 3.5

Hydraulic 502

Standard	Option
Ø31 in 12	Ø58 in 7 Ø65 in 6 Ø90 in 4 Ø130 in 3

Hydraulic 1001

Standard	Option
31Ø in 25	Ø58 in 13 Ø65 in 12 Ø90 in 8.5 Ø130 in 6

FS 800

400 x 18 100 x 20

It's What's Inside That Counts -
That's the Peddinghaus Difference

PDF [84 KB]

10 advantages that speak for Peddinghaus steelworkers

1

2

3

height adjustable and swing-away
stripper with exchangeable plate

electrical safety tripping system
with integrated low-pressure punch spotter
operated via two-stage foot pedal,
socket for connecting an electrical contact
length stop

hydraulic cylinder
integrated in the machine frame,
detachable from the slide

4

5

precision-guided punch slide
with adjustable prismatic guide

safety stroke and stroke position adjustment for achieving high stroking rate

6

7

8

wide flat shear blades,
reversible, with four cutting edges,
vertical shearing movement

large section shear station
with vertical blade movement
for cutting angle iron in ideal
V position

for rapid positioning of workpieces
during punching and shearing
Peddinghaus offers a vast range of
gauging tables of modular design

9

10

optimum tooling supply,
also for punches and dies,
is provided by the Peddinghaus
tooling service

new design and vertical movement
of the notcher also make it possible
to work small dimension channel sections
